3D Sonar Visualizer™ F3D-S is our news solution that works in conjunction with the Full-circle Color Scanning Sonar FSV-25/FSV-25S to show fish and sonar information in 3 dimensions.
Content from our commercial partners
3D Sonar Visualizer™ F3D-S is our news solution that works in conjunction with the Full-circle Color Scanning Sonar FSV-25/FSV-25S to show fish and sonar information in 3 dimensions. It uses the hull unit of your existing sonar but then processes the information in a unique way to show fish, peaks and sea floor data in a 3 dimensional “real world” view. The seabed can be removed from the picture to leave just what you want to see… Fish. Clearly see the size and shape of midwater fish marks to assess the best way to fish them and, with careful and simple adjustment of the depth line control, remove the seabed echoes to visualize fish schools close to the seabed.
Intuitive Interface
Get easy access to all the useful functions that will facilitate your fishing activities. Among them, 4 functions that you will not be able to forget:
3D-View mode
The 3D-View mode allows you to view the surroundings from all angles. It is the ideal tool to have for an accurate 3D representation of the area.
Top-View mode
The Top-View mode displays all echoes in a single horizontal plane around your ship. This mode allows you to accurately assess the horizontal distance to a fish school and know its direction with precision.
Side-View mode
The Side-View mode displays all echoes in a single vertical plane as seen from the stern of the ship. When the “Rotate Top-View/Side-View” mode is activated, this vertical section image is linked to the viewpoint of the 3D-View mode. This mode is used to measure the depth of a school of fish.
Vslice-View mode
The Vslice-View mode shows the echoes in a vertical plane and in a specific orientation, same as the vertical echoes of FSV-25/25S. It can display vertical planes in two different directions. The Vslice-View mode is very useful for viewing the echo in a vertical plane at a specific direction. In addition, it makes it possible to compare the depth of two targets located in two different directions.
Several features
・3D Sonars superiority over 2D Sonars
・Fish schools of surface to middle layer can be observed at the same time.
- Clear to see the exact distribution of fish schools at a glance
- Easy to deduce the optimum tilt angle for the horizontal mode
- Simple and reliable monitoring of any object underwater
・Movement of fish schools can be viewed instantly.
3D Sonar Visualizer™ allows fishermen to
- Prevent by-catch
- Anticipate fish escape
・All-around 3D visualization of fish schools and gear.
・Store and replay both screen images and equipment settings.
・4 Display Views: 3D, Top View, Side View and Vertical Slice.
・InstantAccess bar™ for direct access to menus.
・Easy and immediate entry of common marks: Echo Area, Event, Purse Net, Trawl, etc.
Designed to upgrade your 2D Sonar model FSV-25 / FSV-25S
This product is compatible with FULL-CIRCLE COLOR SCANNING SONAR FSV-25/25S.
